Explosion Proof Light HDA Series
HDA Explosion Proof Headlamp is ideal for a wide variety of uses including industrial safety, public porks, utilities, law enforcement, hardware/tool, automotive, marine, sporting goods and consumer applications. It can be either worn on the head or attached to a hard hat with the included elastic or rubber straps,allowing users to either wear the unit directly or mount it to their hard hats for ease of operation.
Inquiry
Description
Model EX-002W-HDA 1 EX-002W-HDA 2
ATEX Standard I M1 Ex ia op is I Ma
II 1G Ex ia op is IIC T4 Ga
II 1D Ex ia op is IIIC T130°C Da IP54
IECEx Standard Ex ia op is I Ma
Ex ia op is IIC T4 Ga
Ex ia op is IIIC T130°C Da IP54
Area of Classification(Gas) Zones 0, 1 and 2, Gas, Groups IIC
Temp. Classification(Gas) T4
Area of Classification (Dust) Zones 20, 21 and 22, Dust, Groups IIIC
Max. Surface Temperature (Dust) 130°C
Type of Protection  “ia” intrinsic safety
Ambient Temperature  ‘-20°C to +40°C
Beam Type High/Low/Flashing
Light Source Output EX-002W-HDA(1): 118/60 lm
EX-002W-HDA(2): 155/132/78/34 lm
Light Source Lifespan >25000 Hours
Voltage 4.5V
Power Rating 2W
Battery(Included) 3xAAA Batteries
Battery Type Alkaline
Battery Level Indicator  Full-time Battery Indicator
Light Duration EX-002W-HDA(1): 7.5/16h
EX-002W-HDA(2): 6.4/5.5/8/14h
IP 54
