Ex-proof Electronics
Seal Bushings Series EX-AG

Applications

These plugs and sockets are used for connecting electrical equipment to power supply in hazardous locations.

. All Petroleum Production and Refinery
. Petroleum Loading and Transportation
. Petroleum Storage and Retail
. Paint Facilities
. Pumping Stations in any Environment
. Metal Smelting, Foundry and Fabrication
. Ming Operations and Service
. Ocean Platform Facilities and Structure
. Aerospace Clean Room and Production
. Chemical Production and Storage
. Ocean Vessel Operations
. Military Space Conditions
. Flour and Fine Particle Production and Storage
. Food and Distilling Production
. Electrical Power Generation and Stations
. Other high humidity, high vapor, high dust and  high temperature locations

Inquiry
Description

Features
Copper-free aluminum, powder coated surface;

Widely used for isolating seal between pipes or pipes and explosion-proof enclosures;

Five types available.


Rating and Certificates

EN60079

IEC60079

UL1203 and UL50

Class l,Division 1, Groups A,B,C,D

Class l,Division 2, Groups A,B,C,D

Class ll,Division 1, Groups E,F,G

Class ll,Division 2, Groups F,G

Class lll

Marine and Wet Locations

IECEX

ATEX

5 years limited warranty and any other warranty period specified in agreement



Typical model

Product Code Female thread "A" Dimensions (mm) Cable outer diameter (mm)
Metric NPT A B
Type Z M20x1.5 1/2" 77 54 8-10
M25x1.5 3/4" 87 65 10-14
M32x1.5 1" 102 78 12-17
M40x1.5 1 1/4" 130 87 15-23
M50x1.5 1 1/2" 130 92 17-26
M63x1.5 2" 140 107 25-35
Type H M20x1.5 1/2" 74 95 8-10
M25x1.5 3/4" 74 101 10-14
M32x1.5 1" 74 107 12-17
M40x1.5 1 1/4" 98 115 15-23
M50x1.5 1 1/2" 98 134 17-26
M63x1.5 2" 120 142 25-35
Type P M20x1.5 1/2" 88 61 8-10
M25x1.5 3/4" 100 74 10-14
M32x1.5 1" 111 83 12-17
M40x1.5 1 1/4" 130 116 15-23
M50x1.5 1 1/2" 130 121 17-26
M63x1.5 2" 140 143 25-35



Warranty

• Only offer 5 year's warranty or any other warranty period specified in the contract for the product from the date of purchase:
• Invoice or shipment bill is required to claim the warranty.
• The warranty policy only requires manufacturer to repair the defective product or send substitute for replacement.
• Installation labor, electricity cost and other related cost will not be covered by the manufacturer warranty policy.
• Warranty doesn't cover the defect caused by inappropriate use, especially if directions of the instructions for use are not observed, normal abrasion as well as failures which affect the value or use of the product insignificantly.



Download the data sheets below or contact our sales rep. for more information.
