Ex-proof Electronics
Alloy Bushings Series EX-HC

Applications

These plugs and sockets are used for connecting electrical equipment to power supply in hazardous locations.

. All Petroleum Production and Refinery
. Petroleum Loading and Transportation
. Petroleum Storage and Retail
. Paint Facilities
. Pumping Stations in any Environment
. Metal Smelting, Foundry and Fabrication
. Ming Operations and Service
. Ocean Platform Facilities and Structure
. Aerospace Clean Room and Production
. Chemical Production and Storage
. Ocean Vessel Operations
. Military Space Conditions
. Flour and Fine Particle Production and Storage
. Food and Distilling Production
. Electrical Power Generation and Stations
. Other high humidity, high vapor, high dust and  high temperature locations

Inquiry
Description

Features
Ex e enclosure, copper free aluminum, power coated surface;

Environment temperature: -60℃ - +100℃;

Widely used for connection in steel pipe wiring system.


Rating and Certificates

EN60079

IEC60079

UL1203 and UL50

Class l,Division 2, Groups A,B,C,D

Class ll,Division 1, Groups E,F,G

Class ll,Division 2, Groups F,G

Class lll

Marine and Wet Locations

IECEX

ATEX

5 years limited warranty and any other warranty period specified in agreement



Typical model

Product Code Female thread "A" Dimensions (mm)
  Metric NPT W H L
Type A M20x1.5 1/2" 35 45 110
M25x1.5 3/4" 38 49 118
M32x1.5 1" 45 54 145
M40x1.5 1 1/4" 54 65 170
M50x1.5 1 1/2" 60 70 176
M63x1.5 2" 72 83 204
Type B M20x1.5 1/2" 52 45 110
M25x1.5 3/4" 55 49 118
M32x1.5 1" 63.5 54 145
M40x1.5 1 1/4" 71 65 170
M50x1.5 1 1/2" 80 71 176
M63x1.5 2" 93.5 83 204
Type C M20x1.5 1/2" 69 45 110
M25x1.5 3/4" 72 49 118
M32x1.5 1" 80 54 145
M40x1.5 1 1/4" 88 65 170
M50x1.5 1 1/2" 100 71 176
M63x1.5 2" 115 83 204
Type D M20x1.5 1/2" 52 45 101
M25x1.5 3/4" 55 49 108
M32x1.5 1" 63 54 135
M40x1.5 1 1/4" 71 65 162.5
M50x1.5 1 1/2" 80 71 165.5
M63x1.5 2" 93.5 83 194.5
Type E M20x1.5 1/2" 52 45 101
M25x1.5 3/4" 55 49 108
M32x1.5 1" 63 54 135
M40x1.5 1 1/4" 71 65 162.5
M50x1.5 1 1/2" 80 71 165.5
M63x1.5 2" 93.5 83 194.5
Type F M20x1.5 1/2" 35 62 101
M25x1.5 3/4" 38 66 108
M32x1.5 1" 46 71 135
M40x1.5 1 1/4" 54 82 162.5
M50x1.5 1 1/2" 60 91 165.5
M63x1.5 2" 72 104 192.5
Type G M20x1.5 1/2" 35 62 101
M25x1.5 3/4" 38 66 118
M32x1.5 1" 46 71 145
M40x1.5 1 1/4" 54 82 170
M50x1.5 1 1/2" 60 91 176
M63x1.5 2" 72 104 204
Type H M20x1.5 1/2" 30 51 84
M25x1.5 3/4" 35 53 89
M32x1.5 1" 41 64 108
M40x1.5 1 1/4" 51 69 116
M50x1.5 1 1/2" 57 76 130
M63x1.5 2" 70 95 168
