Applications
Fire Control, Oil field, Metallurgy, Railway, Electricity, Police, Petrochemicals and other industries.
Specifications
Ex-mark: Ex dib II CT6
Protection Class: IP68 (100m)
| No. | Specification | Unit | Datas | ||
|
1 |
Rated Voltage | V | 14.8 | ||
| 2 | Rated Capacity | Ah | 2.2 | ||
| 3 | Rated Power | W | 9 | ||
| 4 | LED | Operating Voltage | V | 12 | |
| Current | Strong light | mA | 700 | ||
| Normal light | 220 | ||||
| Luminous Flux | Strong light | lm | 1180 | ||
| Normal light | 360 | ||||
| Average service life | h | 100000 | |||
| 5 | Discharge time | Strong light | h | ≥5 | |
| Normal light | ≥10 | ||||
| Flash light | 20 | ||||
| 6 | Recharge hours | h | ≤6 | ||
| 7 | Battery life | Rechargeable | Appr 1000 times | ||
| 8 | Dimension | Length | mm | 147 | |
| Diameter | 68.5 | ||||
| 9 | Weight | kg | 0.7 | ||
