Shoe Box F Series

Features:

• IP65, Battery backup.

• Extra photocell sensor available.

• Motion sensor and daylight sensor.

• Color changeable and power adjustable.

• Comes with multiple bracket options, 5-year warranty on the entire luminaire.

• Specialized design for outdoor parking lots and wide areas with super slim design.

• System luminous efficiency 140 lumens per watt, with lifespan of more than 50,000 hours.

Applications:

Industrial and commercial applications.

For road and area lighting, such as tunnels, parking lots, auto dealerships, high masts,

apartments, residential complexes, shopping malls, sporting complexes and fields,

educational facilities, streets, roadways, parks, etc.

Description

Specifications:

Model	F1	F2	F3	F4	F5
Wattage	60W/80W/100W	60W/80W/100W /120W/150W	60W/80W/100W/120W /150W/200W	60W/80W/100W/120W /150W/200W/300W	60W/80W/100W/120W /150W/200W/300W
Wattage	60W/80W/100W	60W/80W/100W /120W/150W	60W/80W/100W/120W /150W/200W	60W/80W/100W/120W /150W/200W/300W	60W/80W/100W/120W /150W/200W/300W
Light Efficiency	140 lm/w
Input Voltage	AC 100-277V/277-480V
Power Frequency	50/60Hz
Power Efficiency	94%
Power Factor	0.95
Heat Radiator	Die-Cast Aluminum
Beam Angle	T2 T3 T4
CRI	70 / 80
CCT	2700K-6500K
Working Lifespan	＞50000 hours
IP Rating	WET LOCATION AND IP65
Carton Dimensions(SF Bracket)	577x282x146(mm)	600x380x130(mm)	625x380x130(mm)	830x405x125(mm)	890x405x125mm (mm)
Carton Dimensions(AAM Bracket)	515x282x146(mm)	600x380x130(mm)	645x380x130(mm)	830x405x125(mm)	890x405x125mm (mm)
Net Weight(KG)	3.6	5	5.2	6	6.5
Gross Weight(KG)	4.8	6.5	6.7	8	8.5

* Other Models are fixed CCT option: 2700K-6500K.

* F4(200W) and F5(300W) are changeable CCT option: 3500K/400K/5000K. (With a switch to change CCT)
